Automatic Roll To Roll Slitting Machine Jumbo Roll Slitting Machine

Place of Origin : Zhejiang, China

Brand Name : Sunrise

Certification : CE Certificate

Packaging Details : wooden case

Supply Ability : 50 Set/Sets per Month

Price : $4,335.00/sets >=1 sets

Model Number : SR-350Fll

MOQ : 1 sets

Payment Terms : T/T

Condition : New

Type : Slitting Rewinder

Computerized : NO

Voltage : 220v

Power : 2kw

Dimension(L*W*H) : 1200*800*1280mm

Weight : 400kg

Warranty : 1 Year, 1 Year, 1 Year

After-sales Service Provided : Engineers available to service machinery overseas

Product name : label slitting and rewinding machine

Function : Slitting Rewinding JUMBO Paper Roll

Speed : 120m/min

Usage : paper, film, foam, plastic

Port : Ningbo/Shanghai

Contact Now

Automatic Roll To Roll Slitting Machine Jumbo Roll Slitting Machine

Technical Data:

model

SR-350T

SR-450T

Slitting speed

120m/min

120m/min

Max. Width

320mm

4200mm

Max. Unwinding diameter

500mm

500mm

Max. rewinding diameter

480mm

500mm

Min. Slitting width

16mm

16mm

Max. Slitting width

310mm

410mm

Accuracy rate

±0.10mm

±0.10mm

Voltage

380v

380v

Main motor power

2kw

2kw

weight

400kg

500kg

Dimension

1100*800*1280mm

1200*900*1200mm

Product Descriptions:

SR-320F/420F is automatic slitting machine, which is a matched machine with die cutting machine, it is suitable to slit narrow paper, it can automatic meter, set length, automatic stop, automatic web-guiding and so on functions. Whole machine is with compact structure,running fast,high efficiency,high accuracy,easy-operation,running stably etc features.

Features:

  • Turret shaft, and easy to change different size of rewind shaft
  • All shafts automatic inflate air
  • This standard machine with 3 magnetic tension controllers.
  • Machine with 2 sets of 1inch shafts

Main Parts:

NO. Parts Name Brand
1 Web-guide eyes Baideli
2 Transducer TAIWAN SHILIN
3 counter sensor Germany-sick
4 Proximity Switch China
5 Power Switch French--Schneider
6 Relay China--Chnt
7 Buttons French--Schneider
8 A.C.Contactor China--Chnt

Machine details:

Automatic Roll To Roll Slitting Machine Jumbo Roll Slitting MachineAutomatic Roll To Roll Slitting Machine Jumbo Roll Slitting MachineAutomatic Roll To Roll Slitting Machine Jumbo Roll Slitting MachineAutomatic Roll To Roll Slitting Machine Jumbo Roll Slitting MachineAutomatic Roll To Roll Slitting Machine Jumbo Roll Slitting MachineAutomatic Roll To Roll Slitting Machine Jumbo Roll Slitting MachineAutomatic Roll To Roll Slitting Machine Jumbo Roll Slitting MachineAutomatic Roll To Roll Slitting Machine Jumbo Roll Slitting MachineAutomatic Roll To Roll Slitting Machine Jumbo Roll Slitting MachineFinished Products:

Automatic Roll To Roll Slitting Machine Jumbo Roll Slitting MachineAutomatic Roll To Roll Slitting Machine Jumbo Roll Slitting Machine

Packing & Delivery:

Automatic Roll To Roll Slitting Machine Jumbo Roll Slitting MachineAutomatic Roll To Roll Slitting Machine Jumbo Roll Slitting Machine

Automatic Roll To Roll Slitting Machine Jumbo Roll Slitting Machine

Company Details:

Wenzhou Sunrise Macinery Co.,Ltd professionally research and manufacture label die cutting machine, label slitting machine and some related series products, we pay attention to talents and the technical innovation, insist on "technical innovationnational brand' as development strategy, to make company as the leader in after printing machinery line. Sincerity, quality,service is our operation principle, to be braveaggressivepragmaticefficient is our company spirit. We research and manufacture various of types of machines, welcome all old and new customers and friends to visit us!
